Tried Macro with the D500 and the 105mm Nikon Micro Lens

L

leeinla

Senior Member
I am really impressed with this camera. The camera and the lens are a bit heavy but you get great pics. I am on the fence on whether to purchase the D500 or the D7200. The menu system can be intimating on the D500. How do you guys setup the F1 button and F2 button for Macro and Birding photography? I do have a question about lenses. I plan to go for the Sigma 105 Macro lens, do I need to purchase a teleconverter from Nikon or Sigma? Here are a few of my photos. I would like to get a little closer. Any suggestions would be great.

Whiskeyman

Whiskeyman

Senior Member
If you want to get closer, get extension tubes in order to allow focusing at smaller distances. If you want to enlarge the subject image upon the sensor, get teleconverters.

WM

N

nickt

Senior Member
Also, an extension tube will not degrade the image, there is no glass in it. A teleconverter will degrade some. But with the extension tube, you will lose infinity, that is, you won't be able to focus at a distance. So you will be stuck doing macro when the tube is installed.

How close do you want to get? Here is a shot with the Sigma 105 and d7200. Original and two crops of the same shot.




B

Blacktop

Senior Member
Whiskeyman said:
If you want to get closer, get extension tubes in order to allow focusing at smaller distances. If you want to enlarge the subject image upon the sensor, get teleconverters.

WM
Click to expand...

As far as I understand it, a teleconverter will not enlarge the image using a macro lens at its closest focusing distance. It will still only be a 1:1 magnification. It will however give you a longer working distance.

A 60mm macro lens at its closest focusing distance will give the same size image on the sensor as a 150mm macro lens at it's closest focusing distance.
An extension tube, will increase magnification.

Last edited:
Whiskeyman

Whiskeyman

Senior Member
Blacktop said:
As far as I understand it, a teleconverter will not enlarge the image using a macro lens at its closest focusing distance. It will still only be a 1:1 magnification. It will however give you a longer working distance.

A 60mm macro lens at its closest focusing distance will give the same size image on the sensor as a 150mm macro lens at it's closest focusing distance.
An extension tube, will increase magnification.
Click to expand...

That may be the case. My post was to point out the basic function of each piece of equipment. It is simplistic, but has served me well in the years since I was taught the difference between the two back in high school photography. As far as using a teleconverter on a macro lens, I've never tried it, but why wouldn't it enlarge the image? Before I tried it, I'd check compatibility with the lens, though.

WM

Whiskeyman

Whiskeyman

Senior Member
Blacktop said:
As far as I understand it, a teleconverter will not enlarge the image using a macro lens at its closest focusing distance. It will still only be a 1:1 magnification. It will however give you a longer working distance.

A 60mm macro lens at its closest focusing distance will give the same size image on the sensor as a 150mm macro lens at it's closest focusing distance.
An extension tube, will increase magnification.
Click to expand...

My post was to point out the basic function of each piece of equipment. It is simplistic, but has served me well in the years since I was taught the difference between the two back in high school photography. As far as using a teleconverter on a macro lens, I've never tried it, but why wouldn't it enlarge the image? Before I tried it, I'd check compatibility with the lens, though.

WM

B

Blacktop

Senior Member
Whiskeyman said:
My post was to point out the basic function of each piece of equipment. It is simplistic, but has served me well in the years since I was taught the difference between the two back in high school photography. As far as using a teleconverter on a macro lens, I've never tried it, but why wouldn't it enlarge the image? Before I tried it, I'd check compatibility with the lens, though.

WM
Click to expand...

Because a 1:1 macro lens will still only give you 1;1 magnification using a TC. Like I said earlier, a 60 mm macro lens will give a same size image as a 150 mm macro lens. So lets say I put a 1.4TC on my 100mm Tokina to make it essentially a 140 mm FOV. It will not make the image larger at closest focusing distance. What it will give me is a longer minimum focusing distance to get to 1:1

Whiskeyman

Whiskeyman

Senior Member
Blacktop said:
Because a 1:1 macro lens will still only give you 1;1 magnification using a TC. Like I said earlier, a 60 mm macro lens will give a same size image as a 150 mm macro lens. So lets say I put a 1.4TC on my 100mm Tokina to make it essentially a 140 mm FOV. It will not make the image larger at closest focusing distance. What it will give me is a longer minimum focusing distance to get to 1:1
Click to expand...

Ok, I can see the theoretical merit to what you're saying, but now I'm just going to have to demonstrate it to really believe it. Hopefully I can find a cooperative good subject tomorrow, after I get my yard work finished. (And also that I can move after digging up azaleas in my yard this evening.)

WM

B

Blacktop

Senior Member
Whiskeyman said:
Ok, I can see the theoretical merit to what you're saying, but now I'm just going to have to demonstrate it to really believe it. Hopefully I can find a cooperative good subject tomorrow, after I get my yard work finished. (And also that I can move after digging up azaleas in my yard this evening.)

WM
Click to expand...

Just dig up a worm!:)

B

Blacktop

Senior Member
Whiskeyman said:
But I'm gonna take pictures. I'm not going to have time to go fishing!! ;)

Seriously, now that you mention it, I didn't see a single earthworm digging today; the soil is too sandy.

WM
Click to expand...

Something was bugging me about my own post earlier, the more I started to think about it.
I said.

Because a 1:1 macro lens will still only give you 1;1 magnification using a TC.
Click to expand...


Turns out, I was wrong! I started thinking that if you put a piece of glass (TC) between your camera body and lens, that this will also increase the minimal focusing distance like an extension tube would, giving a greater then 1:1 magnification.
After doing some Googling it turns out that my original answer was wrong. Putting a TC on a Macro lens will in fact increase magnification.
I apologize for steering you wrong. I will now put foot in mouth. :(

E

Elliot87

Senior Member
Blacktop said:
Something was bugging me about my own post earlier, the more I started to think about it.
I said.



Turns out, I was wrong! I started thinking that if you put a piece of glass (TC) between your camera body and lens, that this will also increase the minimal focusing distance like an extension tube would, giving a greater then 1:1 magnification.
After doing some Googling it turns out that my original answer was wrong. Putting a TC on a Macro lens will in fact increase magnification.
I apologize for steering you wrong. I will now put foot in mouth. :(
Click to expand...

I'm pleased that you're wrong about this one :) as I was under the impression that using a TC would increase magnification at minimum focusing distance. It is one of the main reasons I want to get the Kenko 300 Pro 1.4x TC to try on my 200-500mm. I haven't worked out what magnification that would give me but I hope it will make it even better for close up work and extend how long I can wait to get a longer macro than my 55mm 2.8. Unfortunately I can't see the 55mm listed as compatible on Keno charts as I'd like to try it on that too but I won't risk it.

I imagine the D500 and 105mm macro will be a fantastic macro combination, I'd want to try out it's AF system on something like dragonflies in flight!

hark

hark

Administrator
Staff member
Super Mod
Contributor
I imagine you would need the Sigma teleconverter to go with the Sigma 105mm lens.

If you had the Nikon 105mm lens with one of Nikon's teleconverters, you'd lose AF ability. Not sure about the compatibility of the Sigma lens with one of Sigma's teleconverters. Just a heads up to check out compatibility issues before you buy.

Whiskeyman

Whiskeyman

Senior Member
Blacktop said:
Something was bugging me about my own post earlier, the more I started to think about it.
I said.



Turns out, I was wrong! I started thinking that if you put a piece of glass (TC) between your camera body and lens, that this will also increase the minimal focusing distance like an extension tube would, giving a greater then 1:1 magnification.
After doing some Googling it turns out that my original answer was wrong. Putting a TC on a Macro lens will in fact increase magnification.
I apologize for steering you wrong. I will now put foot in mouth. :(
Click to expand...

No worries. Thanks for posting this, though I really wish you to keep your foot out of your mouth; it's hard to hold a camera that way!! :)

I'm still going to demonstrate to myself what happens to min focusing distance and image ratios when using a TC. ("In sight, it must be right!" -- Mr. Steak N. Shake) I wasn't able to make it out with my camera this morning due to something that came up last night, and it is beastly uncomfortable outside right now. I may have to go buy some flowers and work on this indoors.

WM

S

Shoknaw

Senior Member
I don't have the 105 Macro lens so I am forced to use my 200-500 for bug pictures. :)


This from about 7 or 8 feet. No crop straight from camera.
This looks somewhat better at full 7.57 file size.

Last edited:
C

captain birdseye

Senior Member
A 2x converter will give 2;1 magnification on a macro lens at minimum focus distance.
I think it is the minimum focus distance that will remain the same.
An extension tube will give a shorter minimum focus distance and a larger image.
